Royal Inland Hospital

311 Columbia Street Kamloops BC

Application:

1. Roof Top Maintenance (RTM)
2. Scheduled Exterior Building Maintenance
3. Unscheduled Exterior Building Maintenance

Product:

1. Fall Arrest and Restraint Anchors

Station Square Site #4

Station Square, at 35 storeys, with retail at ground level, is the fourth of a five-phase project on a 12-acre site with five landmark towers each with phenomenal panoramic views. Station Square rises before you as a sleek concrete and glass tower inspired by iconic skyscrapers in other metropolitan cities.

With some portions of the tower at over 300 feet tall, Atlas designed a Davit and Socket system for these locations, enabling window cleaning or exterior building maintenance from a suspended Platform or “Swing Stage”.

On green roof areas at the podium levels, Atlas provided specific equipment to enable safe landscape maintenance of these green areas.

Construction Type:

1. Concrete
2. Steel
3. New Construction

Application:

1. Roof Top Maintenance
2. Powered Platform Unscheduled Exterior Maintenance

Product:

1. Davit System
2. SystemStabilization Receptacles

The Spot

2888 Cambie Street, Vancouver

Developed by Shato Holdings, which is famed of its ownership of White Spot, this 8-story concrete commercial/residential building is on the site of an old White Spot restaurant on the Cambie and W 12th Street. It is just steps above Vancouver City Hall and has 160 condo units that range from 1 to 3 bed rooms.

The unique design of this building presented its own challenges with tapered cantilevers and large roof top decks making access some areas of the building a challenge. Atlas proposed a combination of single point anchors, horizontal life lines and underhung rope guides to provide safe access to the building façade.

Applications:

1. Building Roof top Maintenance (RTM)
2. Unscheduled Exterior Building Maintenance

Products:

1. Fall Arrest and Restraint Anchors
2. Horizontal Lifeline System (HLL)

Bill & Melinda Gates Foundation Campus

500 5th Ave N, Seattle, WA 98109, USA

Funded by Bill & Melinda Gates Foundation and designed by Seattle-based NBBJ, this $500 million campus has three six-story office buildings and will be the new home for the Foundation with total capacity of 2,100 staff. Adjacent to Seattle downtown landmark Space Needle, these buildings sit on 12 acres ex-parking lot and will be completed into 2 phases, 900,000 sf for the first two buildings and 400,000 sf for the third building respectively.

The project adopted lots of sustainable features including large living roofs, rainwater storage, thermal energy storage, smart light and ventilation, native and non-invasive landscapes etc. This campus is the world largest LEED Platinum non-profit building, and is planned to last 100 years instead of the typical 20 to 30 year timeline envisioned for typical office space projects.

Atlas US team worked closely with client to ensure this is the most efficient and best aesthetic solution for full coverage, and that critical construction timelines were achieved.

Applications:

1. Building Roof top Maintenance (RTM)
2. Scheduled Exterior Building Maintenance
3. Unscheduled Exterior Building Maintenance

Products:

1. Monorail System
2. Fall Arrest and Restraint Anchors

Translink SkyBridge

Surrey, BC

The SkyBridge is a cable-stayed bridge in Metro Vancouver. Built between 1987 and 1989, it spans the Fraser River and connects New Westminster with Surrey, and carries only the Skytrain (no automobiles). The bridge has two 123-metre tall towers and carries trains 45 metres above the Fraser River and valley. The main span is 340 metres and the total length is 616 metres, making it the longest cable-supported transit-only bridge in the world.

The SkyBridge has two tracks to let the TransLink Skytrain to pass either way on the bridge. A third set of rails in the middle is used by maintenance crews to truck equipment back and forth on the bridge.

This is a retrofit project of which 2 custom A-Frame were installed inside the concrete tower and 2 spiral anchors to be attached to I beam over openings to lower level for Confined Spaces Rescue Equipment. The equipment is being installed in the Sky Train Bridge connecting New West to Surrey. Work was completed during revenue hours but care had to be taken when moving to different location while the system was in operation.

Applications:

1. Unscheduled Exterior Building Maintenance

Products:

1. Vertical Lifeline System (VLL)

One Burrard Place

1281 Hornby St, Vancouver

As one of the last buildings designed by Vancouver’s world-renowned architect, Bing Thom, the stunning landmark mixed-use development features a signature 54-storey skyscraper with sweeping views of English Bay, the North Shore Mountains and the Downtown Skyline.

The building has 810 condo units including 87 rental units, and over a million square feet residential and commercial space.

A 13-storey AAA offices tower at Burrard Place will animate one of the most prominent corners of one of Vancouver’s most notable streets. Complementing the curving glass of the exterior, the office interiors will be among the finest in the city.

Specifications:

• 3 stage Telescopic Boom
• Safe Working Load of 600lbs / 272 kg
• Track Gauge 12 feet
• Height Coverage Max. 200m
• Hoist Unit Type 4 Wire Rope, Multi-Layer Drum Hoist
• Reach 23000 mm from main slewing to suspension
• Glass Replacement Unit

Applications:

1. Scheduled Exterior Building Maintenance
2. Unscheduled Exterior Building Maintenance

Products:

1. Building Maintenance Unit

Silver Tower

6333 Silver Avenue, Burnaby, BC

One of the newest towers to go up in the thriving Metrotown area, The Silver is a prime example of the range of ATLAS’ abilities. We have incorporated a davit system into The Silver to facilitate scheduled and unscheduled building maintenance operations. Rooftop maintenance operations at the lower podium levels has been accomplished with a combination of horizontal lifelines at the perimeter gardens and single point pedestal anchors on the green roofs.

Applications:

1.  Roof Top Maintenance
2.  Scheduled Exterior Building Maintenance
3.  Unscheduled Exterior Building Maintenance

Products:

1. Fall Arrest and Restraint Anchors
2. Horizontal Lifeline Systems
3. Davit System
4. Stabilization System

Evolution Phase II – Pulse

518 6th Ave SE, Calgary AB
Developed by Vancouver’s Embassy BOSA, the three-phase riverfront project – “Evolution” – encompasses high-rise and mid-rise condominium towers, town homes and street-level retail, on the East Village area in Calgary. With an estimated value of $325 million, Evolution will comprise approximately 730,000 square feet of mixed-use development including 600+ residential units.
PULSE, the Evolution’s second phase, is a 33 stories tower built between 2013 and 2016.

Applications:

1. Building Roof top Maintenance (RTM)
2. Scheduled Exterior Building Maintenance
3. Unscheduled Exterior Building Maintenance

Products:

1. Fall Arrest and Restraint Anchors
